RX Series User Manual
Installation 2-5
Step 6
Insert the roll holder support with the screws into the holes of the stand, and then tighten them
up as shown in Figure 2-7 . You could decide roll holder support’s position by inserting into
different holes.
Step 6
Place two roll holders onto the roll holder support and ensure the white protrusion is wedged
in the groove. ( Figure 2-8 )
3 screws
Figure 2-7
Roll holder support
Roll holders
Figure 2-8
Roll holder
support
