RX Series User Manual
Installation 2-6
Step 8
Turn the screw counter-clockwisely for around three times after unpacking the roll holder
( Figure 2-9) .
Step 9
Insert the end of the roll holder without the damper into the left roll holder support and then
insert the end of the roll holder with the damper into the right roll holder support and ensure
the white protrusion is wedged in the groove ( Figure 2-10) .
Figure 2-10
Figure 2-9
