RX Series User Manual
Installation 2-7
Step 10
Tighten the screw on the damper until it is securely attached to the right roll holder support
( Figure 2-11) .
Step 11
Lastly, the complete picture will be shown like below. ( Figure 2-12 )
Figure 2-12
Figure 2-11
