RX Series User Manual
Installation 2-28
Step 6 Remove the screw from the Cut-off Unit (Figure 2-42 and 2-43) and disassemble the
Cut-off Blade Fixer by pulling it up vertically (Figure 2-44).
Screw
Figure 2-42
Figure 2-44
Figure 2-43
