RX Series User Manual
Installation 2-27
Step 5 Remove the entire Cut-off Unit by holding it while pushing the tiny metal board on the
right to the left (Figure 2-39 and 2-40).
The Cut-off Unit will drop automatically once the board is pushed to the left (Figure 2-41).
Push to the left
Metal board
Figure 2-39
Figure 2-40
Figure 2-41
