Step 10 Reconnect the wires at the white Wire Joint (Figure 2-53).
Step 11 Assemble the Tool Carriage Cover back to the Tool Carriage; please locate the end of
the screw to the hole on the carriage before tightening the screw (Figure 2-54).
End of Screw
Figure 2-54
Figure 2-53
