RX Series User Manual
The Control Panel 3-9
Set Tangential
Mode
To enable the tangential-cutting mode for
Note: while the Offset value setting at 0.000 mm, “Set
Tangential Mode” will automatically be disabled.
Enable
Pouncing To make perforated patterns.
* In order to use this function, Pouncing tool must be installed.
* Before start pouncing, place pouncing strip on top of the
cutting pad to protect the cutting pad.
* Set the value as 0 mm to disable the pouncing mode.
* Pouncing tool is an optional item.
0~200mm 0mm
Accept setup command:
To accept commands of the Force, Speed, Cutting Quality,
and Offset only via software.
Accept
setup
command
Panel Setup
Control panel only:
To accept commands of the Force, Speed, Cutting Quality,
and Offset only via control panel of the cutter.
Restore Default
To turn all parameters of the menu items to factory-default
settings.
Save
Parameter
To save pattern(s) of cutting parameters for later use.
There are
4 sets of parameters saved in the panel. Use Page
Up and Page Down keys to select the set of parameters you
wish to adjust, press “Enter” to confirm (the number shown on
the upper left corner will change accordingly). Each set of
parameters includes Speed, Force, Offset, Up Speed, Quality
and Scaling though the latter three will not be displayed in this
section. To adjust or check individual parameters, go back to
the responding keys on the panel and press “Enter” to confirm.
Patterns1~4 Pattern 1
[ MISC ]
Auto Unrolled
Media
To avoid paper jam and motor crash by automatically unroll
media (50cm and up) before cutting while enabled. .
* Auto-unroll only effects on roll/edge media.
* Using Single mode to size media will disable this function
automatically.
* If the length of the rolled media is less than 2 meters or the
weight is light, it is recommended to set this mode disabled.
Auto Unrolled
Speed
To adjust the unrolled media speed. Slow, Normal, Fast
Slow
Rear Paper
Sensor
To detect if th
e rear paper sensor is covered to determine the
following process; when it is enabled, the cutter will detect if
the material has covered the rear paper sensor
and Edge mode; when disabled, the rear paper sensor will
not be functioning.
Note: Rear paper sensor only functions under “Roll” and
“Edge” mode.
Enable
Disable
Enable
Image Scaling
Width
Image Scaling
Length
To adjust the image scale of media length and width that
cause by the thickness of the media.
The Numerator is the ideal length, and the Denominator is
the actual length measured from the resultant.
For example, cutting a line with 500.0 mm length. The
procedure as follows:
1. Press the [LEFT ARROW] to choose the Numerator and
select 500.0 mm,
2. Cut the length by sending a graph file,
3. Measure the length then use the [RIGHT ARROW] key to
choose the Denominator, then
