CHAPTER 5: SETTINGS SETTINGS MENU
C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL 5-3
5

 SETTING GROUP 4


 SETTING GROUP 5


 SETTING GROUP 6

 SETTINGS
 CONTROL ELEMENTS

 TRIP BUS

See page 5-251

 SETTING GROUPS

See page 5-253

 SELECTOR SWITCH

See page 5-254

 TIME OF DAY TIMERS

See page 5-261

 CAPACITOR CONTROL

See page 5-263

 AUTOMATIC VOLTAGE
 REGULATOR
See page 5-267

 DIGITAL ELEMENTS

See page 5-271

 DIGITAL COUNTERS

See page 5-274

 MONITORING
 ELEMENTS
See page 5-276
 SETTINGS
 INPUTS / OUTPUTS

 CONTACT INPUTS

See page 5-292

 VIRTUAL INPUTS

See page 5-294

 CONTACT OUTPUTS

See page 5-295

 VIRTUAL OUTPUTS

See page 5-298

 RESETTING

See page 5-298

 DIRECT INPUTS

See page 5-299

 DIRECT OUTPUTS

See page 5-300
 SETTINGS
 TRANSDUCER I/O

 DCMA INPUTS

See page 5-305

 RTD INPUTS

See page 5-306

 DCMA OUTPUTS

See page 5-307
 SETTINGS
 TESTING

TEST MODE
FUNCTION: Disabled
Range: Disabled, Isolated, Forcible
See page 5-311

TEST MODE FORCING:
On
Range: FlexLogic operand
See page 5-311
