6.4.7 RxGOOSE analogs
ACTUAL VALUES  METERING  RxGOOSE Analogs
The RxGOOSE Analog values display in this menu. The RxGOOSE Analog values are received via IEC 61850 GOOSE
messages sent from other devices.
6.4.8 Transducer inputs/outputs
ACTUAL VALUES  METERING  TRANSDUCER I/O DCMA INPUTS  DCMA INPUT xx
Actual values for each DCmA input channel that is enabled are displayed with the top line as the programmed channel ID
and the bottom line as the value followed by the programmed units.
ACTUAL VALUES  METERING  TRANSDUCER I/O RTD INPUTS  RTD INPUT xx
Actual values for each RTD input channel that is enabled are displayed with the top line as the programmed channel ID
and the bottom line as the value.
6.5 Records
6.5.1 User-programmable fault reports
ACTUAL VALUES  RECORDS  USER-PROGRAMMABLE FAULT REPORTS
This menu displays the user-programmable fault report actual values. See the User-Programmable Fault Report section in
chapter 5 for information on this feature.
 RxGOOSE
 Analogs

RxGOOSE Analog 1
0.000


RxGOOSE Analog 32
0.000
The C70 is provided with optional GOOSE communications capability. This feature is specified as a software
option at the time of ordering. See the Order Codes section of chapter 2 for details.
 DCMA INPUT xx


DCMA INPUT xx
0.000 mA
 RTD INPUT xx


RTD INPUT xx
-50 °C
 USER-PROGRAMMABLE
 FAULT REPORTS

NEWEST RECORD
NUMBER: 0

LAST CLEARED DATE:
2002/8/11 14:23:57

LAST REPORT DATE:
2002/10/09 08:25:27
