CHAPTER 6: ACTUAL VALUES FRONT PANEL
C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL 6-3
6
For status reporting, ‘On’ represents Logic 1 and ‘Off’ represents Logic 0.
6.2 Front panel
6.2.1 Enhanced and standard front panels
The front panel can be viewed and used in the EnerVista software, for example to view an error message displayed on the
front panel.
To view the front panel in EnerVista software:
1. Click Actual Values > Front Panel.
Figure 6-1: Front panel use in the software (C60 shown)

 EVENT RECORDS

See page 6-24

 OSCILLOGRAPHY

See page 6-25

 DATA LOGGER

See page 6-25

 MAINTENANCE

See page 6-26
 ACTUAL VALUES
 PRODUCT INFO

 MODEL INFORMATION

See page 6-27

 FIRMWARE REVISIONS

See page 6-27
