2-10 C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL
ORDER CODES CHAPTER 2: PRODUCT DESCRIPTION
2
2.3.2 Order codes with process bus modules
Table 2-6: C70 order codes for horizontal units with process bus
G3 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
GC | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and enhanced capacitor bank control
GD | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
J0 | | | | | | | IEC 60870-5-103
J3 | | | | | | | IEC 60870-5-103 and IEC 61850
JC | | | | | | | IEC 60870-5-103 and enhanced capacitor bank control
JD | | | | | | | IEC 60870-5-103, IEC 61850, and enhanced capacitor bank control
K0 | | | | | | | IEEE 1588, PRP, and IEC 60870-5-103
K3 | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and IEC 61850
KC | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and enhanced capacitor bank control
KD | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, IEC 61850, and enhanced capacitor bank control
L0 | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, and CyberSentry Lvl 1
L3 | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
LC | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, and enhanced capacitor bank control
LD | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
MOUNT/COATING V | | | | | | Vertical (3/4 rack)
B | | | | | | Vertical (3/4 rack) with harsh-environment coating
FRONT PANEL + INTERFACE F | | | | | English display
D | | | | | French display
R | | | | | Russian display
A | | | | | Chinese display
K | | | | | Enhanced front panel with English display
M | | | | | Enhanced front panel with French display
Q | | | | | Enhanced front panel with Russian display
U | | | | | Enhanced front panel with Chinese display
L | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
W | | | | | Enhanced front panel with Turkish display
Y | | | | | Enhanced front panel with Turkish display and user-programmable pushbuttons
I | | | | | Enhanced front panel with German display
J | | | | | Enhanced front panel with German display and user-programmable pushbuttons
POWER SUPPLY H | | | | 125 / 250 V AC/DC power supply
L | | | | 24 to 48 V (DC only) power supply
ENHANCED DIAGNOSTICS CT/VT DSP
(requires all DSP to be enhanced
diagnostic)
XX | XX | None
8L | 8L | Standard 4CT/4VT with enhanced diagnostics
8M | 8M | Sensitive ground 4CT/4VT with enhanced diagnostics
8N | 8N | Standard 8CT with enhanced diagnostics
8R | 8R | Sensitive ground 8CT with enhanced diagnostics
8V | 8V | Standard 8VT with enhanced diagnostics
CONTACT INPUTS/OUTPUTS XX XX XX None
4C 4C 4C 4 Solid-state (current with optional voltage) MOSFET outputs
6A 6A 6A 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs
6B 6B 6B 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 contact inputs
6C 6C 6C 8 Form-C outputs
6D 6D 6D 16 Contact inputs
6E 6E 6E 4 Form-C outputs, 8 contact inputs
6F 6F 6F 8 Fast Form-C outputs
6G 6G 6G 4 Form-A (voltage with optional current) outputs, 8 contact inputs
6H 6H 6H 6 Form-A (voltage with optional current) outputs, 4 contact inputs
6K 6K 6K 4 Form-C and 4 Fast Form-C outputs
6L 6L 6L 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 contact inputs
6M 6M 6M 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 contact inputs
6N 6N 6N 4 Form-A (current with optional voltage) outputs, 8 contact inputs
6P 6P 6P 6 Form-A (current with optional voltage) outputs, 4 contact inputs
6R 6R 6R 2 Form-A (no monitoring) and 2 Form-C outputs, 8 contact inputs
6S 6S 6S 2 Form-A (no monitoring) and 4 Form-C outputs, 4 contact inputs
6T 6T 6T 4 Form-A (no monitoring) outputs, 8 contact inputs
6U 6U 6U 6 Form-A (no monitoring) outputs, 4 contact inputs
6V 6V 6V 2 Form-A outputs, 1 Form-C output, 2 Form-A (no monitoring) latching outputs, 8 contact inputs
6W 6W 6W 30 Contact inputs - pin terminals (max 4 modules)
6X 6X 6X 18 Form-A (no monitoring) outputs - pin terminals (max 4 modules)
TRANSDUCER INPUTS/OUTPUTS 5A 5A 5A 4 DCmA inputs, 4 DCmA outputs (only one 5A module is allowed)
INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)
For the last module, rear slot P is used for digital
input/output modules; rear slot R is used for inter-
relay communications modules.
2G IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
2H IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels
2i Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1300 nm, single-mode, Laser
2J Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1300 nm, single-mode, Laser
77 IEEE C37.94, 820 nm, multimode, LED, 2 Channels
7H 820 nm, multimode, LED, 2 Channels
7I 1300 nm, multimode, LED, 2 Channels
7S G.703, 2 Channels
7W RS422, 2 Channels
C70 - * ** - * * * - F ** - H ** - M ** - P ** - U ** - W/X ** Full Size Horizontal Mount
BASE UNIT C70 | | | | | | | | | | | Base Unit
CPU T | | | | | | | | | | RS485 with 3 100Base-FX Ethernet, multimode, SFP with LC
U | | | | | | | | | | RS485 with 1 100Base-TX Ethernet, SFP RJ-45 + 2 100Base-FX Ethernet, multimode,
SFP with LC
V | | | | | | | | | | RS485 with 3 100Base-TX Ethernet, SFP with RJ-45
W | | | | | | | | | | RS485 with 2 100Base-FX Ethernet, multimode ST + 10/100Base-TX Ethernet, RJ-45
SOFTWARE OPTIONS 00 | | | | | | | | | No software options
03 | | | | | | | | | IEC 61850
12 | | | | | | | | | Enhanced capacitor bank control (time and date, capacitor control supervision,
automatic voltage regulator)
13 | | | | | | | | | Enhanced capacitor bank control and IEC 61850
A0 | | | | | | | | | CyberSentry Lvl 1
A3 | | | | | | | | | CyberSentry Lvl 1 and IEC 61850
AC | | | | | | | | | CyberSentry Lvl 1 and enhanced capacitor bank control
AD | | | | | | | | | CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
B0 | | | | | | | | | IEEE 1588
B3 | | | | | | | | | IEEE 1588 and IEC 61850
BC | | | | | | | | | IEEE 1588 and enhanced capacitor bank control
BD | | | | | | | | | IEEE 1588, IEC 61850, and enhanced capacitor bank control
C0 | | | | | | | | | Parallel Redundancy Protocol (PRP)
C70 - * ** - * * * - F ** - H ** - M ** - P/R ** Reduced Size Vertical Mount (see note regarding P/R slot below)
