2-12 C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL
ORDER CODES CHAPTER 2: PRODUCT DESCRIPTION
2
Table 2-7: C70 order codes for reduced-size vertical units with process bus
C70 - * ** - * * * - F ** - H ** - M ** - P/R ** Reduced Size Vertical Mount (see note regarding P/R slot below)
BASE UNIT C70 | | | | | | | | | Base Unit
CPU T | | | | | | | | RS485 with 3 100Base-FX Ethernet, multimode, SFP with LC
U | | | | | | | | RS485 with 1 100Base-TX Ethernet, SFP RJ-45 + 2 100Base-FX Ethernet, multimode, SFP with LC
V | | | | | | | | RS485 with 3 100Base-TX Ethernet, SFP with RJ-45
W | | | | | | | | RS485 with 2 100Base-FX Ethernet, multimode ST + 10/100Base-TX Ethernet, RJ-45
SOFTWARE OPTIONS 00 | | | | | | | No software options
03 | | | | | | | IEC 61850
12 | | | | | | | Enhanced capacitor bank control (time and date, capacitor control supervision, automatic voltage
regulator)
13 | | | | | | | Enhanced capacitor bank control and IEC 61850
A0 | | | | | | | CyberSentry Lvl 1
A3 | | | | | | | CyberSentry Lvl 1 and IEC 61850
AC | | | | | | | CyberSentry Lvl 1 and enhanced capacitor bank control
AD | | | | | | | CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
B0 | | | | | | | IEEE 1588
B3 | | | | | | | IEEE 1588 and IEC 61850
BC | | | | | | | IEEE 1588 and enhanced capacitor bank control
BD | | | | | | | IEEE 1588, IEC 61850, and enhanced capacitor bank control
C0 | | | | | | | Parallel Redundancy Protocol (PRP)
C3 | | | | | | | PRP and IEC 61850
CC | | | | | | | PRP and enhanced capacitor bank control
CD | | | | | | | PRP, IEC 61850, and enhanced capacitor bank control
D0 | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D3 | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
DC | | | | | | | IEEE 1588, CyberSentry Lvl 1, and enhanced capacitor bank control
DD | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
E0 | | | | | | | IEEE 1588 and PRP
E3 | | | | | | | IEEE 1588, PRP, and IEC 61850
EC | | | | | | | IEEE 1588, PRP, enhanced capacitor bank control
ED | | | | | | | IEEE 1588, PRP, IEC 61850, and enhanced capacitor bank control
F0 | | | | | | | PRP and CyberSentry Lvl 1
F3 | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
FC | | | | | | | PRP, CyberSentry Lvl 1, and enhanced capacitor bank control
FD | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
G0 | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G3 | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
GC | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and enhanced capacitor bank control
GD | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
J0 | | | | | | | IEC 60870-5-103
J3 | | | | | | | IEC 60870-5-103 and IEC 61850
JC | | | | | | | IEC 60870-5-103 and enhanced capacitor bank control
JD | | | | | | | IEC 60870-5-103, IEC 61850, and enhanced capacitor bank control
K0 | | | | | | | IEEE 1588, PRP, and IEC 60870-5-103
K3 | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and IEC 61850
KC | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and enhanced capacitor bank control
KD | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, IEC 61850, and enhanced capacitor bank control
L0 | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, and CyberSentry Lvl 1
L3 | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
LC | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, and enhanced capacitor bank control
LD | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and enhanced capacitor bank control
MOUNT/COATING V | | | | | | Vertical (3/4 rack)
B | | | | | | Vertical (3/4 rack) with harsh environmental coating
FRONT PANEL + INTERFACE F | | | | | English display
D | | | | | French display
R | | | | | Russian display
A | | | | | Chinese display
K | | | | | Enhanced front panel with English display
M | | | | | Enhanced front panel with French display
Q | | | | | Enhanced front panel with Russian display
U | | | | | Enhanced front panel with Chinese display
L | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
W | | | | | Enhanced front panel with Turkish display
Y | | | | | Enhanced front panel with Turkish display and user-programmable pushbuttons
I | | | | | Enhanced front panel with German display
J | | | | | Enhanced front panel with German display and user-programmable pushbuttons
POWER SUPPLY H | | | | 125 / 250 V AC/DC power supply
L | | | | 24 to 48 V (DC only) power supply
PROCESS BUS MODULE XX | XX | None
| 81 | | Standard 4CT/4VT with enhanced diagnostics
CONTACT INPUTS/OUTPUTS XX None
| 4 Solid-state (current with optional voltage) MOSFET outputs
| 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs
| 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 contact inputs
| 8 Form-C outputs
| 16 Contact inputs
| 4 Form-C outputs, 8 contact inputs
| 8 Fast Form-C outputs
| 4 Form-A (voltage with optional current) outputs, 8 contact inputs
| 6 Form-A (voltage with optional current) outputs, 4 contact inputs
| 4 Form-C and 4 Fast Form-C outputs
| 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 contact inputs
| 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 contact inputs
| 4 Form-A (current with optional voltage) outputs, 8 contact inputs
| 6 Form-A (current with optional voltage) outputs, 4 contact inputs
| 2 Form-A (no monitoring) and 2 Form-C outputs, 8 contact inputs
| 2 Form-A (no monitoring) and 4 Form-C outputs, 4 contact inputs
| 4 Form-A (no monitoring) outputs, 8 contact inputs
| 6 Form-A (no monitoring) outputs, 4 contact inputs
| 2 Form-A outputs, 1 Form-C output, 2 Form-A (no monitoring) latching outputs, 8 contact inputs
| 30 Contact inputs - pin terminals (max 4 modules)
| 18 Form-A (no monitoring) outputs - pin terminals (max 4 modules)
