5-166 C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL
FLEXLOGIC CHAPTER 5: SETTINGS
5
ELEMENT:
Bank phase
overvoltage
BANK OV 1 STG 1A PKP
BANK OV 1 STG 1B PKP
BANK OV 1 STG 1C PKP
BANK OV 1 STG 2A PKP
BANK OV 1 STG 2B PKP
BANK OV 1 STG 2C PKP
BANK OV 1 STG 3A PKP
BANK OV 1 STG 3B PKP
BANK OV 1 STG 3C PKP
BANK OV 1 STG 4A PKP
BANK OV 1 STG 4B PKP
BANK OV 1 STG 4C PKP
BANK OV 1 PKP A
BANK OV 1 PKP B
BANK OV 1 PKP C
BANK OV 1 PKP
BANK OV 1 DPO
BANK OV 1 STG 1A OP
BANK OV 1 STG 1B OP
BANK OV 1 STG 1C OP
BANK OV 1 STG 2A OP
BANK OV 1 STG 2B OP
BANK OV 1 STG 2C OP
BANK OV 1 STG 3A OP
BANK OV 1 STG 3B OP
BANK OV 1 STG 3C OP
BANK OV 1 STG 4A OP
BANK OV 1 STG 4B OP
BANK OV 1 STG 4C OP
BANK OV 1 OP A
BANK OV 1 OP B
BANK OV 1 OP C
BANK OV 1 OP
Bank overvoltage element 1 picked up in phase A of stage 1
Bank overvoltage element 1 picked up in phase B of stage 1
Bank overvoltage element 1 picked up in phase C of stage 1
Bank overvoltage element 1 picked up in phase A of stage 2
Bank overvoltage element 1 picked up in phase B of stage 2
Bank overvoltage element 1 picked up in phase C of stage 2
Bank overvoltage element 1 picked up in phase A of stage 3
Bank overvoltage element 1 picked up in phase B of stage 3
Bank overvoltage element 1 picked up in phase C of stage 3
Bank overvoltage element 1 picked up in phase A of stage 4
Bank overvoltage element 1 picked up in phase B of stage 4
Bank overvoltage element 1 picked up in phase C of stage 4
Bank overvoltage element 1 picked up in phase A
Bank overvoltage element 1 picked up in phase B
Bank overvoltage element 1 picked up in phase C
Bank overvoltage element 1 picked up
Bank overvoltage element 1 dropped out
Bank overvoltage element 1 operated in phase A of stage 1
Bank overvoltage element 1 operated in phase B of stage 1
Bank overvoltage element 1 operated in phase C of stage 1
Bank overvoltage element 1 operated in phase A of stage 2
Bank overvoltage element 1 operated in phase B of stage 2
Bank overvoltage element 1 operated in phase C of stage 2
Bank overvoltage element 1 operated in phase A of stage 3
Bank overvoltage element 1 operated in phase B of stage 3
Bank overvoltage element 1 operated in phase C of stage 3
Bank overvoltage element 1 operated in phase A of stage 4
Bank overvoltage element 1 operated in phase B of stage 4
Bank overvoltage element 1 operated in phase C of stage 4
Bank overvoltage element 1 operated in phase A
Bank overvoltage element 1 operated in phase B
Bank overvoltage element 1 operated in phase C
Bank overvoltage element 1 operated
BANK OV 2 to 3 Same set of operands as shown for BANK OV 1
ELEMENT:
Breaker flashover
BKR 1 FLSHOVR PKP A
BKR 1 FLSHOVR PKP B
BKR 1 FLSHOVR PKP C
BKR 1 FLSHOVR PKP
BKR 1 FLSHOVR OP A
BKR 1 FLSHOVR OP B
BKR 1 FLSHOVR OP C
BKR 1 FLSHOVR OP
BKR 1 FLSHOVR DPO A
BKR 1 FLSHOVR DPO B
BKR 1 FLSHOVR DPO C
BKR 1 FLSHOVR DPO
Breaker 1 flashover element phase A has picked up
Breaker 1 flashover element phase B has picked up
Breaker 1 flashover element phase C has picked up
Breaker 1 flashover element has picked up
Breaker 1 flashover element phase A has operated
Breaker 1 flashover element phase B has operated
Breaker 1 flashover element phase C has operated
Breaker 1 flashover element has operated
Breaker 1 flashover element phase A has dropped out
Breaker 1 flashover element phase B has dropped out
Breaker 1 flashover element phase C has dropped out
Breaker 1 flashover element has dropped out
ELEMENT:
Breaker arcing
BKR ARC 1 OP
BKR ARC 1 DPO
BKR ARC 1 MAX OP
BKR ARC 1 MAX DPO
BKR ARC 2 OP
BKR ARC 2 DPO
BKR ARC 2 MAX OP
BKR ARC 2 MAX DPO
Breaker arcing current 1 has operated
Breaker arcing current 1 has dropped out
Breaker arcing current 1 max interrupting current has operated
Breaker arcing current 1 max interrupting current has dropped out
Breaker arcing current 2 has operated
Breaker arcing current 2 has dropped out
Breaker arcing current 2 max interrupting current has operated
Breaker arcing current 2 max interrupting current has dropped out
BKR ARC 3 Same set of operands as shown for BKR ARC 1
ELEMENT:
Breaker failure
BKR FAIL 1 RETRIPA
BKR FAIL 1 RETRIPB
BKR FAIL 1 RETRIPC
BKR FAIL 1 RETRIP
BKR FAIL 1 T1 OP
BKR FAIL 1 T2 OP
BKR FAIL 1 T3 OP
BKR FAIL 1 TRIP OP
Breaker failure 1 re-trip phase A (only for 1-pole schemes)
Breaker failure 1 re-trip phase B (only for 1-pole schemes)
Breaker failure 1 re-trip phase C (only for 1-pole schemes)
Breaker failure 1 re-trip 3-phase
Breaker failure 1 timer 1 is operated
Breaker failure 1 timer 2 is operated
Breaker failure 1 timer 3 is operated
Breaker failure 1 trip is operated
BKR FAIL 2 to 3 Same set of operands as shown for BKR FAIL 1
