6-28 C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL
PRODUCT INFORMATION CHAPTER 6: ACTUAL VALUES
6
The shown data is illustrative only. A modification file number of 0 indicates that, currently, no modifications have been
installed.
6.6.2.2 Graphical front panel
ACTUAL VALUES PRODUCT INFO FIRMWARE REVISIONS
The shown data is illustrative only. A modification file number of 0 indicates that, currently, no modifications have been
installed. The date format reflects the format specified for the clock and can vary from that shown here.
BOOT DATE:
2013/09/15 16:41:32
Range: YYYY/MM/DD HH:MM:SS
Date and time when the boot program was built.
FPGA PROGRAM
REVISION: 02.02
Range: 0.00 to 655.35
Revision number for FPGA.
FPGA DATE:
2016/09/15 16:41:32
Range: YYYY/MM/DD HH:MM:SS
Date and time when the FPGA was built.
FIRMWARE REVISIONS
C70 Relay
REVISION: 7.6x
Range: 0.00 to 655.35
Revision number of the application firmware.
MODIFICATION FILE
NUMBER: 0
Range: 0 to 65535 (ID of the MOD FILE)
Value is 0 for each standard firmware release.
BOOT PROGRAM
REVISION: 7.01
Range: 0.00 to 655.35
Revision number of the boot program firmware.
COMPILE DATE:
2017/06/15 04:55:16
Range: YYYY/MM/DD HH:MM:SS
Date and time when product firmware was built.
BOOT DATE:
2016/09/15 16:41:32
Range: YYYY/MM/DD HH:MM:SS
Date and time when the boot program was built.
GFP PROGRAM
REVISION: 7.60
Range: 0.00 to 655.35
Revision number of front panel program firmware.
GFP COMPILE DATE:
2017/03/03 12:58:00
Range: YYYY/MM/DD HH:MM:SS
Date/time when graphical front panel firmware built.
GFP BOOT PROGRAM
REVISION: 1.00
Range: 0.00 to 655.35
Revision number of panel boot program firmware.
GFP BOOT COMP. DATE:
2017/03/03 12:58:00
Range: YYYY/MM/DD HH:MM:SS
Date/time when panel boot program was built.
FPGA PROGRAM
REVISION: 02.02
Range: 0.00 to 655.35
Revision number for FPGA.
FPGA DATE:
2016/09/15 16:41:32
Range: YYYY/MM/DD HH:MM:SS
Date and time when the FPGA was built.
