K114 Issue No. 9
Druck ADTS 405 User Manual 3 - 25
3
3.16 Options
WARNINGS:
1. COMPLY WITH ALL LOCAL SAFETY ORDERS.
2. OBSERVE ALL SAFETY PROCEDURES IN THE AIRCRAFT MAINTENANCE
MANUALS.
SCPI IEEE 488 Option
The SCPI IEEE 488 interface provides remote control of the ADTS 405 from a suitable
PC, using standardised commands.
The ADTS 405 implements the full SCPI command set with the exception of expressions
and units suffixes. Although all the ADTS 405 commands at the first, or root, level are
fully defined in the SCPI standard, many of the functions required have not been
allowed for in the standard. The lower levels of commands have been created using
the appropriate rules contained within the standard.
Druck publication K157 SCPI User Manual provides details of command codes,
command syntax and examples of programming. Section 5 of this manual details a
test procedure for the option.
Altimeter Encoder Option
The Altimeter Encoder Option allows the output from encoder altimeters to be
displayed on either the hand terminal or display and key-pad of the unit. The
displayed data includes the bit pattern and the equivalent altitude decoded from the
bit pattern. The unit supplies 24 VDC to power the altimeter encoder electronics circuit
and the altimeter vibrator circuit.
Druck publication K170 Altimeter Encoder Option User Manual provides details of
displayed and encoded data. Section 5 of this manual details a test procedure for the
option.
ARINC 429 Option
The ARINC 429 Interface provides the ADTS 405 with the ability to continuously
transmit all internal aeronautical and pressure measurement parameters. Through an
appropriate connector, the ADTS 405 can transmit the measurement parameters to
the aircraft systems. The ADTS 405 can also monitor the aircraft ARINC 429 bus and
display the measurement data on the hand terminal or the front panel display. The
labels used for transmitting and receiving each parameter conform to the standard
429 specification.
Druck publication K185 ARINC 429 Option User Manual provides details of parameters
and data output. Section 5 of this manual details a test procedure for the option.
