Performing an Exam
2-38
LOGIQ E9
–
User Guide
Direction 5454884-100 English
Rev. 1
Slope mm/s Timeline Display ±5%, not to exceed
1mm/s
M-Mode Only
Doppler Sample
Volume Depth (SVD)
mm Full Screen 2mm (0.2cm) in any
direction
When SVD is at
least half the
depth of the image
Velocity cm/s Full Range 10% PW and CW
Doppler Mode
Doppler Angle
Correction
degrees From 0-59°
From 60-90°
±1%
±2%
Table 2-6: System Measurements and Accuracies (Continued)
Measurement Units Useful Range Accuracy
Limitations or
Conditions
