LOGIQ E9
–
User Guide
Direction 5454884-100 English
Rev. 1
Table 3-6: System Overview
Applications
• Abdominal
• Obstetrical
• Gynecological
• Breast
• Small parts
• Vascular
• Peripheral
• Transcranial
• Pediatric and Neonatal
• Musculoskeletal
• Urological
• Cardiac
Scanning Methods
• Electronic Sector
• Electronic Convex
• Electronic Linear
• Mechanical Volume Sweep
Operating Modes
• B-Mode
• M-Mode
• Color Flow (CFM)
• B-Flow (option)
• B-Flow Color (option)
• Extended Field of View (LOGIQView Option)
• Power Doppler Imaging (PDI)
• PW Doppler
• CW Doppler (option)
• Volume Modes-3D/4D
• 3D Static
• 4D Real Time (Option)
• Anatomical M-Mode
• Coded Contrast Imaging (Option) [not available in
the US]
• Elastography (Option)
Display Modes
• Simultaneous Capability [B or CrossXBeam/PW; B
or CrossXBeam/CFM or PDI; B/M; B/
CrossXBeam; Realtime Triplex Mode (B or
CrossXBeam + CFM or PDI/PW)]
• Selectable alternating Modes [B or CrossXBeam/
PW; B or CrossXBeam + CFM (PDI)/PW; B/CW
(option)]
• Colorized Image - Colorized B - Colorized M -
Colorized D
• Time line Display [Independent Dual B or
CrossXBeam/PW Display; CW Display; 2 Display
Formats; Top/Bottom or Side/Side selectable
Format; Size: 1/2: 1/2; 1/3: 2/3 (full format,
switchable after freeze); 2 Timeline Methods:
Scrolling or Moving Bar
• Virtual Convex
• Multi Image Split/Quad Screen [Live and/or
Frozen, B or CrossXBeam+B or CrossXBeam/
CFM or PDI, PW/M, Independent Cine playback]
• Zoom: Write/Read/Pan
Transducer Types
• Sector Phased Array
• Convex Array
• Micro convex Array
• Linear Array
• Matrix Array
• Volume probe (4D)
• Convex Array
• Micro convex Array
• Linear Array
• Split Crystal
