GE LOGIQ E9

After the Exam is Over
3-52 LOGIQ E9 – User Guide
Direction 5454884-100 English
Rev. 1
Table 3-7: System Parameters
Controls Available on Freeze or Recall
• Max Read Zoom to 8
• B/M/CrossXBeam Mode (Gray Map; TGC,
Colorized B and M; Frame Average [Loops only];
Dynamic Range)
• PW-Mode (Gray Map; Post Gain; Baseline Shift;
Sweep Speed; Invert Spectral Waveform;
Compression; Rejection, Colorized Spectrum;
Display Format; Angle Correct; Quick Angle
Correct, Auto Angle Correct)
• Color Flow (Overall Gain [Loops and Stills]; Color
Map; Transparency Map; Frame Averaging [Loops
only]; Flash Suppression, CFM Velocity Tag, CFM
Display Threshold; Spectral Invert for Color/
Doppler)
• Automatic Optimization
• SRI-HD
• CrossXBeam (display non-compounded and
compounded image siultaneously in split screen)
• 3D Reconstruction from a stored CINE loop
• 4D (Gray Map, Colorize; Post Gain; Change
display between single, dual, quad sectional or
rendered)
• Anatomical M-Mode
• Anatomical M-Mode on CINE Loop
Controls Available While “Live”
• Write Zoom
• B/M/CrossXBeam-Mode (Gain; TGC; Dynamic
Range; Acoustic Output; Transmission Focus
Position; Transmission Focus Number; Line
Density Control; Sweep Speed for M-Mode; # of
Angles for CrossXBeam)
• PW-Mode (Gain; Dynamic Range; Acoustic
Output; Transmission Frequency; PRF; Wall Filter;
Spectral Averaging; Sample Volume Gate for
PW-Mode Length and Depth; Velocity Scale;
Doppler Audio)
• Color Flow (CFM Gain; CFM Velocity Range;
Acoustic Output; Wall Echo Filter; Packet Size;
Frame Rate Control; CFM Spatial Filter; CFM
Frame Averaging; CFM Line Resolution;
Frequency/Velocity Baseline Shift)
Scanning Parameters
• Digital Beamformer
• Imaging Depth: 0-36cm [Minimum: 0-2 cm (Zoom);
Maximum: 0-36 cm]
• Continuous Dynamic Receive Focus/Continuous
Dynamic Receive Aperture
• Adjustable Dynamic Range
• Adjustable Field of View [FOV]
• Image Reverse: Right/ Left
• Image Rotation: 0 and 180 degrees
Image Storage
• Storage Format: DICOM, Export JPEG, WMV
(MPEG4), AVI
• Storage Devices: USB Memory Stick (64MB to
64GB; CD-R Storage (700MB); DVD-R Storage
(4.7GB); Hard Drive Image Storage (~137GB)
CINE Memory/Image Memory
• 776 MB of CINE Memory
• Selectable CINE Sequence for CINE Review
• Prospective CINE Mark
• Measurements/Calculations & Annotations on
CINE Playback
• Scrolling timeline memory
• Dual Image CINE Display
• Quad Image CINE Display
• CINE Gauge and CINE Image Number Display
• CINE Review Loop
• CINE Review Speed
• Retrospective CINE
• Prospective CINE
