Brightness
Adjusting the monitor's brightness is one of the most important
factors for proper image quality. If these controls are set
incorrectly, the Gain, TGC, Dynamic Range and even Power
Output may have to be changed more often than necessary to
compensate.
The proper setup displays a complete gray scale. The lowest
level of black should just disappear into the background and the
highest white should be bright, but not saturated.
To adjust the brightness:
1. Press the right adjustment button to increase brightness.
2. Press the left adjustment button to decrease brightness.
The amount of brightness is shown on a slide bar on the
screen.
Figure 1-9. Brightness adjustment button
1. Adjustment (+) Button
2. Adjust (-) Button
Record any changes to the final brightness settings and leave
this information with the system. Generally speaking, do not
change the controls once they have been set. Once set, the
display then becomes the reference for the hard copy device(s).
NOTE: After readjusting the monitor's Brightness, readjust all preset
and peripheral settings.
Table 1-2: Brightness Settings (Recommended)
Room Condition Brightness
Dark Room (Factory default) 60
Bright Room 100


GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
