DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
Section 9-9 - Cables 9 - 17
703 Top Cable Assy 3 5252346
Front USB Cable, MIC
Cable
1. MIC Cable,
Connect one side
(Label:MIC) to LP6 Front
USB Bracket and another
side (Label: J205) to PCB
Silk J205 of Backplane
Assy
2. Front USB Cable,
Connect one side (Label:
F_USB) to LP6 Front USB
Bracket and another side
(Label: J14) to Label J14 of
ARP Assy
11Yes Yes
704 ACPC Cable II 5168846
Connect one side(Label:
J3) to PCB Silk "J3" of LP6
Backplane and another
side(Label:CON2, T-FAN)
to Label CON2 and T-FAN
of Internal ACPC Con
Cable Assy 2
11Yes Yes
705 Printer Cable Assy 1 5177395
Connect one side to BW
Printer Power cable and
another side to External
Printer (short cable)
11Yes Yes
706 Printer Cable Assy 2 5168842
Connect one side to BW
Printer Power cable and
another side to External
Printer(long cable)
11Yes Yes
707 HDD/ODD Cable Set 5252342
EIDE Cable II, SATA Cable,
DVD Power Cable
1. EIDE Cable II,
Connect one side
(Label:ODDI) to LP6 ODD
Assy and another side
(Label: J204) to PCB Silk
J204 of LP6 Backplane
Assy
2. SATA Cable,
Connect one side to LP6
HDD Assy and another side
to LP6 Backplane Assy
3. DVD Power Cable,
Connect one side
(Label:ODD) to LP6 APS II
Assy and another side to
LP6 ODD Assy
11Yes Yes
708 APS II AC Power Cable 5252347
Connect one side
(Label:APS II) to Label APS
II of LP6 APS II Assy
and another side (Label:
CON3) to Label CON3 of
AC Out Cable
11Yes Yes
Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X
Table 9-9 Cables
