DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
9 - 18 Section 9-9 - Cables
709 Peripheral AC Power Cable 5165244
Connect one side (Label
CON5) to Label CON5 of
AC Out Cable and another
side (Label: CON6) to Label
CON6 of ARP Assy
11Yes Yes
710 AEXP Cable 5172066
Connect one side (Label
J13) to Label PCB Silk J13
of Syscon Assy
and another side (Label:
J15) to Label J15 of ARP
Assy
11Yes Yes
711 DCWD Cable II Assy 5257056
Connect one side to DCWD
Bracket and another
side(Label: J7) to PCB Silk
J7 of CWD64 Assy
11Yes Yes
712 IEC Type ECG CABLE 5196518
ECG Patient cable only for
Japan
11Yes Yes
713 AHA Type ECG CABLE 5196519
ECG Patient cable for Asia,
US, Europe
11Yes Yes
Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X
Table 9-9 Cables
To Next Page
