F-18 F650 Digital Bay Controller GE Multilin
F.1 FACTORY DEFAULT CONFIGURATION APPENDIX F
F
F.1.2 FACTORY DEFAULT CONFIGURATION
NOTE:
SOURCE COLUMN:
This columns allow selecting the simple or complex (OR signal or Virtual output) operand that actives the selected
elements on relay configuration
If more than one operands are selected, the relay performs an OR gate with them to activate the selected element.
SIGNAL LOGIC COLUMN:
Refers to each individual signal selected on its left. NOT legend means that the refered signal is inverted
SOURCE LOGIC COLUMN:
Refers to the whole SOURCE signal selected on its left. NOT legend means that SOURCE signal is inverted
If more than one operand were selected, the OR gate output is inverted
SETPOINT>RELAY CONFIGURATION>OUTPUTS
OUTPUT ID OUTPUT NAME SOURCE SIGNAL
LOGIC
SOURCE
LOGIC
CONT OP OPER_F_01 79 BLOCKED AR BLOCK BY LEVEL
CONT OP OPER_F_02 27/59 PKP
VO_046_59P_PKP
VO_045_27P_PKP
CONT OP OPER_F_03 50/67G PKP VO_048_50G_PKP
CONT OP OPER_F_04 51/67G PKP VO_049_51G_PKP
CONT OP OPER_F_05 50/67P PKP
VO_051_50PH_PKP
VO_050_50PL_PKP
CONT OP OPER_F_06 51/67P PKP VO_053_51P_PKP
CONT OP OPER_F_07 RECLOSE
OPERATION BIT 1
AR CLOSE BREAKER
CONT OP OPER_F_08 TRIP
OPERATION BIT 2
VO_083_GENERAL_TRIP
CONT OP OPER_G_01 81U/81O TRIP VO_082_ALL_FREQUENCY_TRIP
CONT OP OPER_G_02 27/59 TRIP VO_079_ALL_OVERVOLTAGE_TRIP
CONT OP OPER_G_03 50/67G TRIP VO_068_50G_TRIP
CONT OP OPER_G_04 51/67G TRIP VO_067_51G_TRIP
CONT OP OPER_G_05 50/67P TRIP
VO_059_50PL_TRIP
VO_058_50PH_TRIP
CONT OP OPER_G_06 51/67P TRIP VO_057_51P_TRIP
CONT OP OPER_G_07 RCLS IN PROG AR RCL IN PROGRESS
CONT OP OPER_G_08 RCLS LOCKOUT AR LOCKOUT
CONT OP RESET_F_01 Not Configured
CONT OP RESET_F_02 Not Configured
CONT OP RESET_F_03 Not Configured
CONT OP RESET_F_04 Not Configured
CONT OP RESET_F_05 Not Configured
CONT OP RESET_F_06 Not Configured
CONT OP RESET_F_07 Not Configured
CONT OP RESET_F_08 Not Configured
CONT OP RESET_G_01 Not Configured
CONT OP RESET_G_02 Not Configured
CONT OP RESET_G_03 Not Configured
CONT OP RESET_G_04 Not Configured
