GEK-113032A W650 Wind Generator Protection System 7-9
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
SERVICES AA: TP/MC SERVER (S) W650
REPORTING (CLAUSE 14)
S24 Report TP c6 Yes
S24-1 data-change (dchg) Yes
S24-2 qchg-change (qchg) Yes
S24-3 data-update (dupd) No
S25 GetBRCBValues TP c6 Yes
S26 SetBRCBValues TP c6 Yes
UNBUFFERED REPORT CONTROL BLOCK (URCB)
S27 Report TP c6 Yes
S27-1 data-change (dchg) Yes
S27-2 qchg-change (qchg) No
S27-3 data-update (dupd) No
S28 GetURCBValues TP c6 Yes
S29 SetURCBValues TP c6 Yes
c6 - shall declare support for at least one (BRCB or URCB)
LOGGING (CLAUSE 14)
LOG CONTROL BLOCK
S30 GetLCBValues TP M
S31 SetLCBValues TP M
LOG
S32 QueryLogByTime TP M
S33 QueryLogByEntry TP M
S34 GetLogStatusValues TP M
c7 - shall declare support for at least one (QueryLogByTime or QueryLogByEntry)
GENERIC SUBSTATION EVENT MODEL (GSE) (CLAUSE 14.3.5.3.4)
GOOSE-CONTROL-BLOCK
S35 SendGOOSEMessage MC c8
S36 GetReference TP C9
S37 GetGOOSEElementNumber TP C9
S38 GetGoCBValues TP O
S39 SetGoCBValues TP O
GSSE-CONTROL-BLOCK
S40 SendGSSEMessage MC c8 Yes
S41 GetReference TP c9
S42 GetGSSEElementNumber TP c9
S43 GetGsCBValues TP O Yes
S44 SetGsCBValues TP O Yes
c8 - shall declare support for at least one (SendGOOSEMessage or
SendGSSEMessage)
c9- shall declare support if TP association is available
