7-14 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
GNDPIOC: 3 GROUND INSTANTANEOUS OVERCURRENT AND 3 SENS GROUND INSTANTANEOUS
OVERCURRENT.
b) 2.2.2 PTOC (TIME OVERCURRENT)
PHSPTOC: 3 HIGH TIME OVERCURRENT AND 3 LOW TIME OVERCURRENT.
PIOC CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PIOC Instantaneous overcurrent
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str geNeutACD Start O IOC PKP
Op geNeutACT Operate M IOC OP
Blk geNeutACT Blk P IOC BLK
Settings
StrVal geFloatASG Start value M Pickup Level (0,05 – 160)
OpDITmms geFloatASG Operate Delay Time P Trip Delay (0 – 900)
InMagTyp geING_1 Input Type P (Phasor o RMS)
RsDl geFloatASG Reset Delay P (0 - 900)
PIOCEna geSPG Function IOC enable P Function
PTOC CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTOC Time overcurrent
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M TOC PKP
Op gePhsACT Operate M TOC OP
Blk gePhsACT Block P TOC BLK
Settings
TmACrv geCURVE Operating curve type M Curve
StrVal geFloatASG Start value O Pickup Level (0,05 - 160)
TmMult geFloatASG Time dial multiplier O TD Multiplier (0 – 900)
RsMod geING_2 Reset Mode P Reset (instantaneous, lineal)
InMagTyp geING_1 Input Type P Input (Phasor, RMS)
VolRst geSPG Voltage Restraint P (enable, Disable)
PTOCEna geSPG Function TOC enable P Function
