7-20 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
7.2.3.3 LOGICAL NODES FOR PROTECTION RELATED FUNCTIONS. LN GROUP: R
a) RDIR (DIRECTIONAL ELEMENT)
PHSRDIR: 3 PHASE DIRECTIONAL ELEMENTS
RDIR CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
RDIR Directional Element
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Dir gePhsACD Direction M
Op gePhsACT Operate P Phase Dir OP
Blk gePhsACT Block P Phase Dir Block
BlkIn geGeneralACT Phase Dir Blk Inp P Phase Dir Blk Inp
Settings
ChrAng geFloatASG Characteristic Angle O (-90, 90) MTA
BlkValV geIntASG Minimun operating current O (0, 850) Pol V Threshold
PolOpMod geING_3 Direction P (Forward, Reverse)
BlkMod geING_4 Block Logica P (Permission, Block)
RDIREna geSPG Function Permission P (Enable, Disable)
