GEK-113032A W650 Wind Generator Protection System 7-19
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
AUXPTUV: 3 AUXILIARY UNDEVOLTAGE.
f) PTUF (UNDERFREQUENCY)
4 UNDEFREQUENCY NODES.
PTUV CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTUV Undervoltage
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TUV PKP
Op geGeneralACT Operate M TUV OP
Blk geGeneralACT Block P TUV BLK
Settings
TmVCrv GeCURVE_2 Operating curve type O Curve ( definitive, inverse )
StrVal geIntASG Start value O Pickup Level (3 – 500)
TmMult geFloatASG Time dial multiplier O Delay (0 – 900)
PTUVEna geSPG Function TUV enable P Function
PTUF CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTUF OverFrequency
DATA
Common Logical Node Information
Mod GeModINC Mode M
Beh GeINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TUF PKP
Op geGeneralACD Operate M TUF OP
Blk geGeneralACT Block P TUF BLK
Settings
StrVal geFloatASG Start value (frequency) O Pickup Level (20-65)
BlkVal geIntASG Voltage Block Value O Minimun Voltage (30-500)
OpDlTmms GeFloatASG Operate Delay Time O Trip Delay (0-900)
RsDlTmms geFloatASG Reset Delay Time O Reset Delay (0-900)
PTOFEna geSPG Function TOF enable P Function (Enable,Disable)
