7-18 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
NEUTPTOV: 3 HIGH NEUTRAL OVERVOLTAGE AND 3 LOW NEUTRAL OVERVOLTAGE.
e) PTUV (UNDERVOLTAGE)
PHSPTUV: 4 PHASE UNDERVOLTAGE
PTOV CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTOV Overvoltage
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TOV PKP
Op geGeneralACT Operate O TOV OP
Blk geGeneralACT Block P TOV BLK
Settings
StrVal geIntASG Start Value O Pickup Level (3 – 500)
OpDlTmms geFloatASG Operate Delay Time O Trip Delay ( 0 – 900 )
RsDlTmms GeFloatASG Reset Delay Time O Reset Delay ( 0 – 900 )
PTOVEna geSPG Function TOV enable P Function
PTUV CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTUV Undervoltage
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TUV PKP
Op geGeneralACT Operate M TUV OP
Blk geGeneralACT Block P TUV BLK
StrPhGn gePhsACD Start P TUV Phase-Gnd PKP
OpPhGn gePhsACT Operate P TUV Phase-Gnd OP
StrPhPh gePhsACD Start P TUV Phase-Phase PKP
OpPhPh gePhsACT Operate P TUV Phase-Phase OP
Settings
TmVCrv GeCURVE_2 Operating curve type O Curve ( definitive, inverse )
StrVal geIntASG Start value O Pickup Level (3 – 850)
TmMult geFloatASG Time dial multiplier O Delay (0 – 900)
DeaLinVal GeIntASG Minimum Voltage P Minimum Voltage (0 – 850)
OpMod GeING_6 Logic P Logic (Any, Two, All phases)
InMod GeING_7 Mode P Phase-Phase, Phase-Ground
BkrMon GeSPG Supervised by 52 P Enable, Disable
PTUVEna geSPG Function TUV enable P Function
