7-22 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
GNDRDI: 3 GROUND DIRECCIONAL ELEMENTS.
RDIR CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
RDIR Directional Element
DATA ATTRIBUTE NAME
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Dir geNeutACD Direction M
Op geNeutACT Operate P Ground Dir OP
Blk geNeutACT Block P Ground Dir Block
BlkIn geNeutACT Ground Dir Blk Inp P Ground Dir Blk Inp
Settings
ChrAng geFloatASG Characteristic Angle O (-90, 90) MTA
BlkValV geIntASG Minimun operating current O (0, 500) Pol V Threshold
PolOpMod geING_3 Direction P (Forward, Reverse)
BlkMod geING_4 Block Logica P (Permission, Block)
RDIREna geSPG Function Permission P (Enable, Disable)
PolQty geING_5 Polarisation O (VO,IP,VO+IP,VO*IP)
