GEK-113032A W650 Wind Generator Protection System 7-23
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
HSERDIR: 3 SENS DIRECCIONAL ELEMENTS.
RDIR CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
RDIR Directional Element
DATA Attribute Name
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Dir geGeneralACD Direction M
Op geGeneralACT Operate P Sens Gnd Dir OP
Blk geGeneralACT Block P Sens Gnd Dir Block
BlkIn geGeneralACT Sens Gnd Dir Blk Inp P Sens Gnd Dir Blk Inp
Settings
ChrAng geFloatASG Characteristic Angle O (-90, 90) MTA
BlkValV geIntASG Minimun operating current O (0, 500) Pol V Threshold
PolOpMod geING_3 Direction P (Forward, Reverse)
BlkMod geING_4 Block Logica P (Permission, Block)
RDIREna geSPG Function Permission P (Enable, Disable)
