7-24 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
b) RREC (AUTORECLOSING)
RREC CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
RREC Autoreclosing
DATA ATTRIBUTE NAME
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
Controls
BlkRec geSPC Block Reclosing O AR Pulse block, unblock
Status Information
Op geGeneralACT Operate M AR Close Breaker
AutoRecSt GeINS_AR Auto Reclosing status M AR Status
AutoRecLO GeINS_AR_LO Auto Reclosing Lockout Status P AR Lockout Mode
AutoRecBlk GeINS_AR_Blk Auto Reclosing Block Status P AR Block Mode
Settings
Rec1Tms GeFloatASG First Reclose Time O Dead Time 1
Rec2Tms GeFloatASG Second Reclose Time O Dead Time 2
Rec3Tms GeFloatASG Third Reclose Time O Dead Time 3
Rec4Tms GeFloatASG Fourth Reclose Time O Dead Time 4
RclTms geFloatASG Reclaim Time O Reclaim Time
MaxNumShots geING Max number of Shots P Max number Shots
RsTms geFloatASG Reclosing --> Ready P Reset Time
HoldTms geFloatASG Cond Check Time P Hold Time
CondEna geSPG Check Cond (Enable, Disable) P Cond Permission
RRECEna geSPG Function Enable, Disable P Function Permission
