GEK-113032A W650 Wind Generator Protection System 7-25
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
7.2.3.4 LOGICAL NODES FOR GENERIC REFERENCES. LN GROUP: G
a) GGIO (GENERIC PROCESS I/O)
BOARDGGIO
¦ 4 NODES MAPPED TO THE BOARDS F, AND G.
GGIO CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
GGIO Generic process I/O
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status information
BoardSt geSPS Board Status P Board Status
Ind1 geSPS General Indication ( binary input ) O Contact Input 1
Ind2 geSPS General Indication ( binary input ) O Contact Input 2
Ind32 geSPS General Indication ( binary input ) O Contact Input 32
Ind33 geSPS General Indication ( binary input ) O Contact Output 1
.. .. .. .. ..
Ind48 geSPS General Indication ( binary input ) O Contact Output 16
Measured Values
AnIn1 GeFloatMV Analogue input O Analog Input 1
AnIn2 GeFloatMV Analogue input O Analog Input 2
AnIn8 GeFloatMV Analogue input O Analog Input 8
