7-26 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
VIRTUALGGIO: 1 NODE FOR READ AND WRITE THE LATCHED AND SELF RESET VIRTUAL INPUTS.
EVENTSGGIO: THIS NODE DATA CAN ORIGINATE AS ANY PLC CONTROL EVENT.
GGIO CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
GGIO Generic process I/O
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status information
Ind1 geSPS General Indication ( binary input ) O Latched Virtual Input 1
Ind2 geSPS General Indication ( binary input ) O Latched Virtual Input 2
..
Ind32 geSPS General Indication ( binary input ) O Latched Virtual Input 32
Controls
DPCSO1 geDPC Double point controllable status output O Latched Virtual Input 1 y 2
DPCSO2 geDPC Double point controllable status output O Latched Virtual Input 3 y4
.. .. .. .. ..
DPCSO16 geDPC Double point controllable status output O Latched Virtual Input 31 y 32
SPCSO1 geSPC Single point controllable status output O Latched Virtual Input 1
SPCSO2 geSPC Single point controllable status output O Latched Virtual Input 2
.. .. .. .. ..
SPCSO32 geSPC Single point controllable status output O Latched Virtual Input 32
SPCSO33 geSPC Single point controllable status output O Self reset Virtual Input 1
SPCSO34 geSPC Single point controllable status output O Self reset Virtual Input 2
.. .. .. .. ..
SPCSO64 geSPC Single point controllable status output O Self reset Virtual Input 32
GGIO CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
GGIO Generic process I/O
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status information
Ind1 geSPS General Indication ( binary input ) O Control Event 1
Ind2 geSPS General Indication ( binary input ) O Control Event 2
Ind192 geSPS General Indication ( binary input ) O Control Event 192
