GEK-113032A W650 Wind Generator Protection System 7-37
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
d) PHASE TO PHASE RELATED MEASURED VALUES OF A THREE PHASE SYSTEM ( DEL )
7.2.4.3 COMMON DATA CLASS SPECIFICATIONS FOR CONTROLLABLE STATUS INFORMATION
a) CONTROLABLE SINGLE POINT (SPC).
DEL CLASS (PHASE TO PHASE RELATED MEASURED VALUES OF A THREE PHASE SYSTEM)
GEINTDEL
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATA
phsAB geIntCMV GC_1
phsBC geIntCMV GC_1
phsCA geIntCMV GC_1
configuration, descripcion and extension
d Vstring255 DC O
GEFLOATDEL
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATA
phsAB geFloatCMV GC_1
phsBC geFloatCMV GC_1
phsCA geFloatCMV GC_1
configuration, descripcion and extension
d Vstring255 DC O
SPC CLASS
GESPC (PARTICULARIZACIÓN OPERATE)
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
Oper
CtlVal Boolean CO AC_CO_M
Origin Originator CO,ST AC_CO_M
orCat ENUMERATED M
orIdent OCTECT64 M
CtlNum INT8U CO,ST M
TBtime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
StVal Boolean ST dchg FALSE | TRUE AC_ST
q BVstring13 ST qchg AC_ST
t Utctime ST AC_ST
configuration, descripcion and extension
CtlModel ENUMERATED CF M
d Vstring255 DC O
