GEK-113032A W650 Wind Generator Protection System A-1
APPENDIX A A.1 LOGIC OPERANDS
A
APPENDIX A LOGIC OPERANDSA.1LOGIC OPERANDS
OPERANDS -650 - MODEL FX - GX
INTERNAL SYSTEM STATUS
Autocheck internal states
TIMER STATUS Real time clock autocheck
E2PROM STATUS
E2prom status :(0) Not configured or problems during
writing process ; (1) Configured and OK
GRAPHIC STATUS Graphic display status
ALARM TEXT ARRAY Text display status
DSP COMM ERROR DSP communication error
MAGNETIC MODULE
ERROR
Magnetic module error
CALIBRATION ERROR Calibration error
Other internal states
USER MAP STATUS User map status: (0) Not configured ; (1) Configured
FACTORY
CALIBRATION
Calibration status (0) Not calibrated ; (1) Relay
calibrated
FLEXCURVE A STATUS User curve A: (0) Not configured (1) Configured
FLEXCURVE B STATUS User curve B: (0) Not configured (1) Configured
FLEXCURVE C STATUS User curve C: (0) Not configured (1) Configured
FLEXCURVE D STATUS User curve D: (0) Not configured (1) Configured
Green Zone Memory internal status
Yellow Zone Memory internal status
Orange Zone Memory internal status
Red Zone Memory internal status
UpTime System Time
Configurable Logic Outputs (512 elements)
VIRTUAL OUTPUT 000 Configurable logic output 000
VIRTUAL OUTPUT 001 Configurable logic output 001
... ...
VIRTUAL OUTPUT 511 Configurable logic output 511
Operation Bits (24 elements)
OPERATION BIT 1
Operation bit 001: (0) the configured time expires or
when success conditions are met;(1) operation 1 is
executed and interlocks are fulfilled.
OPERATION BIT 2
Operation bit 002: (0) the configured time expires or
when success conditions are met;(1) operation 2 is
executed and interlocks are fulfilled.
... ...
OPERATION BIT 24
Operation bit 024: (0) the configured time expires or
when success conditions are met;(1) operation 24 is
executed and interlocks are fulfilled.
Control Event Bits (128 elements)
CONTROL EVENT 1 Control Event 1 Activation Bit
CONTROL EVENT 2 Control Event 2 Activation Bit
... ...
CONTROL EVENT 128 Control Event 128 Activation Bot
Latched Virtual Inputs (32 elements)
LATCHED VIRT IP 1 Latched virtual input 1
LATCHED VIRT IP 2 Latched virtual input 2
... ...
LATCHED VIRT IP 32 Latched virtual input 32
