A-2 W650 Wind Generator Protection System GEK-113032A
A.1 LOGIC OPERANDS APPENDIX A
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Self Reset Virtual Inputs (32 elements)
SELF-RST VIRT IP 1 Self reset virtual input 1
SELF-RST VIRT IP 2 Self reset virtual input 2
... ...
SELF-RST VIRT IP 32 Self reset virtual input 32
Contact Inputs Type 1Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC16 Input 16 (CC16) in Board X
Contact Inputs Type 2 Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC8 Input 8 (CC8) in Board X
CONT IP_X_CC9
(Va_COIL1)
Contact Input 09 (Va_COIL1) for slot X. Input voltage
(Va) detected, Circuit 1. Complete circuit supervised
CONT IP_X_CC10
(Vb_COIL1)
Contact Input 10 (Vb_COIL1) for slot X. Input voltage
(Vb) detected, Circuit 1. Complete circuit supervised
CONT IP_X_CC11
(Va_COIL2)
Contact Input 11 (Va_COIL2) for slot X. Input voltage
(Va) detected, Circuit 1. Complete circuit supervised
CONT IP_X_CC12
(Vb_COIL2)
Contact Input 12 (Vb_COIL2) for slot X. Input voltage
(Vb) detected, Circuit 2. Complete circuit supervised
CONT IP_X_CC13
(O7_SEAL)
Contact Input 13 (07_SEAL) for slot X. Current
detected. Contact output associated with current flow >
100 mA latched
CONT IP_X_CC14
(O8_SEAL)
Contact Input 14 (08_SEAL) for slot X. Current
detected. Contact output associated with current flow >
100 mA latched
CONT IP_X_CC15
(SUP_COIL1)
Contact Input 15 (SUP_COIL1) for slot X. Output for
circuit 1 supervision element
CONT IP_X_CC16
(SUP_COIL2)
Contact Input 16 (SUP_COIL2) for slot X. Output for
circuit 2 supervision element
Contact Inputs Type 4 Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC32 Input 32 (CC32) in Board X
Contact Inputs Type 5 Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC16 Input 8 (CC16) in Board X
Analog_Inp_X_01 Analog Input 01
Analog_Inp_X_02 Analog Input 02
Analog_Inp_X_03 Analog Input 03
... ...
Analog_Inp_X_08 Analog Input 08
