GEK-113032A W650 Wind Generator Protection System A-3
APPENDIX A A.1 LOGIC OPERANDS
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Contact Outputs Type 1 & 2 Board Activation signals
CONT OP OPER_X_01 Logic signal for Output 1 activation. Board X
CONT OP OPER_X_02 Logic signal for Output 2 activation. Board X
... ...
CONT OP OPER_X_08 Logic signal for Output 8 activation. Board X
Contact Outputs Type 1 & 2 Board Reset signals
CONT RESET_X_01 board X, 01 latched output reset
CONT RESET_X_02 board X, 02 latched output reset
... ...
CONT RESET_X_08 board X, 08 latched output reset
Contact Outputs Type 1 & 2 Board Status
CONT OP_X_01 Contact output 1 Board X operation
CONT OP_X_02 Contact output 2 Board X operation
... ...
CONT OP_X_8 Contact output 8 Board X operation
Board Status BOARD X STATUS
Board X status: (0) Inactive - There is no
communication with the board (1) Active - There is
communication with the board
Switchgear status (16 elements)
SWITCH 1 A INPUT Contact input type A to switchgear Function 1
SWITCH 1 B INPUT Contact input type B to switchgear Function 1
SWITCH 2 A INPUT Contact input type A to switchgear Function 2
SWITCH 2 B INPUT Contact input type B to switchgear Function 2
... ...
SWITCH 16 A INPUT Contact input type A to switchgear Function 16
SWITCH 16 B INPUT Contact input type B to switchgear Function 16
Switchgear outputs (16 elements)
SWITCH 1 A STATUS Contact logic output type A from switchgear Function 1
SWITCH 1 B STATUS Contact logic output type B from switchgear Function 1
SWITCH 2 A STATUS Contact logic output type A from switchgear Function 2
SWITCH 2 B STATUS Contact logic output type B from switchgear Function 2
... ...
SWITCH 16 A STATUS Contact logic output type A from switchgear Function 16
SWITCH 16 B STATUS Contact logic output type B from switchgear Function 16
Switchgear states (16 elements)
SWITCH 1 OPEN switchgear 1 open
SWITCH 1 CLOSED switchgear 1 closed
SWITCH 1 00_ERROR Error 00 switchgear 1 (contact A = 0, contact B = 0)
SWITCH 1 11_ERROR Error 11 switchgear 1 (contact A = 1, contact B = 1)
SWITCH 2 OPEN switchgear 2 open
SWITCH 2 CLOSED switchgear 2 closed
SWITCH 2 00_ERROR Error 00 switchgear 2 (contact A = 0, contact B = 0)
SWITCH 2 11_ERROR Error 11 switchgear 2 (contact A = 1, contact B = 1)
... ...
SWITCH 16 OPEN switchgear 16 open
SWITCH 16 CLOSED switchgear 16 closed
SWITCH 16 00_ERROR Error 00 switchgear 16 (contact A = 0, contact B = 0)
SWITCH 16 11_ERROR Error 11 switchgear 16 (contact A = 1, contact B = 1)
