A-4 W650 Wind Generator Protection System GEK-113032A
A.1 LOGIC OPERANDS APPENDIX A
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Switchgear Open-Close Initializing States
SWITCH 1 OPEN INIT Switchgear 1 opening initiation
SWITCH 1 CLOSE INIT Switchgear 1 closing initiation
SWITCH 2 OPEN INIT Switchgear 2 opening initiation
SWITCH 2 CLOSE INIT Switchgear 2 closing initiation
... ...
SWITCH 16 OPEN INIT Switchgear 16 opening initiation
SWITCH 16 CLOSE INIT Switchgear 16 closing initiation
Switchgear Fail States
SWGR 1 FAIL TO OPEN Failure to open Switchgear 1
SWGR 2 FAIL TO OPEN Failure to open Switchgear 2
... ...
SWGR 16 FAIL TO
OPEN
Failure to open Switchgear 16
SWGR 1 FAIL TO
CLOSE
Failure to close Switchgear 1
SWGR 2 FAIL TO
CLOSE
Failure to close Switchgear 2
... ...
SWGR 16 FAIL TO
CLOSE
Failure to close Switchgear 16
LEDS HMI (16 elements)
READY LED
Ready LED: (0-Rojo) Relay out of service, protection
OUT OF ORDER (1-Green) Relay in service; protection
READY
LED 1
Programmable LED 1 status: Red colour. Latched by
hardware. Reset by hardware (ESC) and
programmable (LED RESET INPUT)
LED 2
Programmable LED 2 status: Red colour. Latched by
hardware. Reset by hardware (ESC) and
programmable (LED RESET INPUT)
LED 3
Programmable LED 3 status: Red colour. Latched by
hardware. Reset by hardware (ESC) and
programmable (LED RESET INPUT)
LED 4
Programmable LED 4 status: Red colour. Latched by
hardware. Reset by hardware (ESC) and
programmable (LED RESET INPUT)
LED 5
Programmable LED 5 status: Red colour. Latched by
hardware. Reset by hardware (ESC) and
programmable (LED RESET INPUT)
LED 6
Programmable LED 6 status: Orange colour. Not
latched. Latching possibility via PLC. Reset by
hardware (ESC) and programmable (LED RESET
INPUT)
LED 7
Programmable LED 7 status: Orange colour. Not
latched. Latching possibility via PLC. Reset by
hardware (ESC) and programmable (LED RESET
INPUT)
LED 8
Programmable LED 8 status: Orange colour. Not
latched. Latching possibility via PLC. Reset by
hardware (ESC) and programmable (LED RESET
INPUT)
LED 9
Programmable LED 9 status: Orange colour. Not
latched. Latching possibility via PLC. Reset by
hardware (ESC) and programmable (LED RESET
INPUT)
LED 10
Programmable LED 10 status: Orange colour. Not
latched. Latching possibility via PLC. Reset by
hardware (ESC) and programmable (LED RESET
INPUT)
LED 11
Programmable LED 11 status: Green colour. Not
latched. Latching possibility via PLC. Reset by
hardware (ESC) and programmable (LED RESET
INPUT)
