A-12 W650 Wind Generator Protection System GEK-113032A
A.1 LOGIC OPERANDS APPENDIX A
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Phase TOC Low
PH TOC3 LOW PKP
Phase timed overcurrent element pickup low level
Group 3 any phase
PH TOC3 LOW OP
Phase timed overcurrent element operation (trip) low
level Group 3 any phase
Neutral TOC
NEUTRAL TOC1
BLOCK
Neutral timed overcurrent element block Group 1
NEUTRAL TOC1 PKP Neutral timed overcurrent element pickup Group 1
NEUTRAL TOC1 OP
Neutral timed overcurrent element operation (trip)
Group 1
NEUTRAL TOC2
BLOCK
Neutral timed overcurrent element block Group 2
NEUTRAL TOC2 PKP Neutral timed overcurrent element pickup Group 2
NEUTRAL TOC2 OP
Neutral timed overcurrent element operation (trip)
Group 2
NEUTRAL TOC3
BLOCK
Neutral timed overcurrent element block Group 3
NEUTRAL TOC3 PKP Neutral timed overcurrent element pickup Group 3
NEUTRAL TOC3 OP
Neutral timed overcurrent element operation (trip)
Group 3
Ground TOC
GROUND TOC1 BLOCK Ground timed overcurrent element block Group 1
GROUND TOC1 PKP Ground timed overcurrent element pickup Group 1
GROUND TOC1 OP
Ground timed overcurrent element operation (trip)
Group 1
GROUND TOC2 BLOCK Ground timed overcurrent element block Group 2
GROUND TOC2 PKP Ground timed overcurrent element pickup Group 2
GROUND TOC2 OP
Ground timed overcurrent element operation (trip)
Group 2
GROUND TOC3 BLOCK Ground timed overcurrent element block Group 3
GROUND TOC3 PKP Ground timed overcurrent element pickup Group 3
GROUND TOC3 OP
Ground timed overcurrent element operation (trip)
Group 3
Sensitive Ground TOC
SENS GND TOC1
BLOCK
Sensitive ground timed overcurrent element block
Group 1
SENS GND TOC1 PKP
Sensitive ground timed overcurrent element pickup
Group 1
SENS GND TOC1 OP
Sensitive ground timed overcurrent element operation
(trip) Group 1
SENS GND TOC2
BLOCK
Sensitive ground timed overcurrent element block
Group 2
SENS GND TOC2 PKP
Sensitive ground timed overcurrent element pickup
Group 2
SENS GND TOC2 OP
Sensitive ground timed overcurrent element operation
(trip) Group 2
SENS GND TOC3
BLOCK
Sensitive ground timed overcurrent element block
Group 3
SENS GND TOC3 PKP
Sensitive ground timed overcurrent element pickup
Group 3
SENS GND TOC3 OP
Sensitive ground timed overcurrent element operation
(trip) Group 3
Negative Sequence TOC
NEG SEQ TOC1 BLOCK
Negative sequence timed overcurrent element block
Group 1
NEG SEQ TOC1 PKP
Negative sequence timed overcurrent element pickup
Group 1
NEG SEQ TOC1 OP
Negative sequence timed overcurrent element
operation Group 1
NEG SEQ TOC2 BLOCK
Negative sequence timed overcurrent element block
Group 2
NEG SEQ TOC2 PKP
Negative sequence timed overcurrent element pickup
Group 2
NEG SEQ TOC2 OP
Negative sequence timed overcurrent element
operation Group 2
NEG SEQ TOC3 BLOCK
Negative sequence timed overcurrent element block
Group 3
NEG SEQ TOC3 PKP
Negative sequence timed overcurrent element pickup
Group 3
NEG SEQ TOC3 OP
Negative sequence timed overcurrent element
operation Group 3
