GEK-113032A W650 Wind Generator Protection System A-13
APPENDIX A A.1 LOGIC OPERANDS
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Phase Directional
PHASE DIR1 BLK INP Phase directional block Group 1
PHASE DIR1 BLOCK A Phase directional element block Group 1 Phase A
PHASE DIR1 A OP Phase directional element operation Group 1 Phase A
PHASE DIR1 BLOCK B Phase directional element block Group 1 Phase B
PHASE DIR1 B OP Phase directional element operation Group 1 Phase B
PHASE DIR1 BLOCK C Phase directional element block Group 1 Phase C
PHASE DIR1 C OP Phase directional element operation Group 1 Phase C
PHASE DIR2 BLK INP Phase directional block Group 2
PHASE DIR2 BLOCK A Phase directional element block Group 2 Phase A
PHASE DIR2 A OP Phase directional element operation Group 2 Phase A
PHASE DIR2 BLOCK B Phase directional element block Group 2 Phase B
PHASE DIR2 B OP Phase directional element operation Group 2 Phase B
PHASE DIR2 BLOCK C Phase directional element block Group 2 Phase C
PHASE DIR2 C OP Phase directional element operation Group 2 Phase C
PHASE DIR3 BLK INP Phase directional block Group 3
PHASE DIR3 BLOCK A Phase directional element block Group 3 Phase A
PHASE DIR3 A OP Phase directional element operation Group 3 Phase A
PHASE DIR3 BLOCK B Phase directional element block Group 3 Phase B
PHASE DIR3 B OP Phase directional element operation Group 3 Phase B
PHASE DIR3 BLOCK C Phase directional element block Group 3 Phase C
PHASE DIR3 C OP Phase directional element operation Group 3 Phase C
Neutral Directional
NEUTRAL DIR1 BLK
INP
Neutral directional element block Group 1
NEUTRAL DIR1 BLOCK Neutral directional element block Group 1
NEUTRAL DIR1 OP Neutral directional element operation Group 1
NEUTRAL DIR2 BLK
INP
Neutral directional element block Group 2
NEUTRAL DIR2 BLOCK Neutral directional element block Group 2
NEUTRAL DIR2 OP Neutral directional element operation Group 2
NEUTRAL DIR3 BLK
INP
Neutral directional element block Group 3
NEUTRAL DIR3 BLOCK Neutral directional element block Group 3
NEUTRAL DIR3 OP Neutral directional element operation Group 3
Ground Directional
GROUND DIR1 BLK INP Ground directional element block Group 1
GROUND DIR1 BLOCK Ground directional element block Group 1
GROUND DIR1 OP Ground directional element operation Group 1
GROUND DIR2 BLK INP Ground directional element block Group 2
GROUND DIR2 BLOCK Ground directional element block Group 2
GROUND DIR2 OP Ground directional element operation Group 2
GROUND DIR3 BLK INP Ground directional element block Group 3
GROUND DIR3 BLOCK Ground directional element block Group 3
GROUND DIR3 OP Ground directional element operation Group 3
