B-116 W650 Wind Generator Protection System GEK-113032A
B.7 MEMORY MAP APPENDIX B
B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
Ajustes Sobretensión de Fases Grupo 4 - Phase OV 4
0x39A2 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39A3 Pickup Level F003 1000 R/W 2 [3 , 850] V
0x39A5 Trip Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x39A7 Reset Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x39A9 Logic F012 1000 R/W 1 0=ANY PHASE
1=TWO PHASES
2=ALL PHASES
0x39AA Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39BD Confirmation address W 1
Ajustes Subtensión de Fases Grupo 4 - Phase UV 4
0x39BE Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39BF Mode F012 1000 R/W 1 0=PHASE-PHASE
1=PHASE-GROUND
0x39C0 Pickup Level F003 1000 R/W 2 [3 , 850] V
0x39C2 Curve F012 1000 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
0x39C3 Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x39C5 Minimum Voltage F003 1000 R/W 2 [0 , 850] V
0x39C7 Logic F012 1000 R/W 1 0=ANY PHASE
1=TWO PHASES
2=ALL PHASES
0x39C8 Supervised by 52 F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39C9 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39DC Confirmation address W 1
Ajustes Sobrefrecuencia Grupo 4 - Overfrequency 4
0x39DD Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39DE Pickup Level F003 1000 R/W 2 [20.00 , 65.00] Hz
0x39E0 Trip Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x39E2 Reset Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x39E4 Minimum Voltage F003 1000 R/W 2 [30, 500] V
0x39E6 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39F9 Confirmation address W 1
Ajustes Subfrecuencia Grupo 4 - Underfrequency 4
0x39FA Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x39FB Pickup Level F003 1000 R/W 2 [20.00 , 65.00] Hz
0x39FD Trip Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x39FF Reset Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A01 Minimum Voltage F003 1000 R/W 2 [30, 500] V
0x3A03 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A16 Confirmation address W 1
