GEK-113032A W650 Wind Generator Protection System B-117
APPENDIX B B.7 MEMORY MAP
B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
Ajustes Unidad Direccional Potencia Grupo 4 - Directional Power 4
0x3A17 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A18 Blk Time After Close F003 1000 R/W 2 [0.00 , 900.00] s
0x3A1A Dir Power Angle 1 F003 1000 R/W 2 [0.00 , 359.99] Deg
0x3A1C Stage 1 Tap F003 1000 R/W 2 [-10000.00 , 10000.00] MW
0x3A1E Stage 1 Time F003 1000 R/W 2 [0.00 , 900.00] s
0x3A20 Dir Power Angle 2 F003 1000 R/W 2 [0.00 , 359.99] Deg
0x3A22 Stage 2 Tap F003 1000 R/W 2 [-10000.00 , 10000.00] MW
0x3A24 Stage 2 Time F003 1000 R/W 2 [0.00 , 900.00] s
0x3A26 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A39 Confirmation address W 1
Desequilibrio de Tensión Grupo 1 - Voltage Unbalance 1
0x3A3A Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A3B Pickup Level F003 1000 R/W 2 [0.00 , 500.00] %
0x3A3D Trip Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A3F Reset Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A41 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A4B Confirmation address W 1
Desequilibrio de Tensión Grupo 2 - Voltage Unbalance 2
0x3A4C Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A4D Pickup Level F003 1000 R/W 2 [0.00 , 500.00] %
0x3A4F Trip Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A51 Reset Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A53 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A5D Confirmation address W 1
Desequilibrio de Tensión Grupo 3 - Voltage Unbalance 3
0x3A5E Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A5F Pickup Level F003 1000 R/W 2 [0.00 , 500.00] %
0x3A61 Trip Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A63 Reset Delay F003 1000 R/W 2 [0.00 , 900.00] s
0x3A65 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x3A6F Confirmation address W 1
Ajustes Protocolo CAN OPEN - CAN OPEN Protocol Settings
0x3A70 CANOpen NodeID F004 1000 R/W 1 [1M 127]
0X3A71 CANOpen Baud F012 1000 R/W 1 0 = 125 kbs
1 = 500 Kbs
0x3A76 Confirmation Address W 1
