B-118 W650 Wind Generator Protection System GEK-113032A
B.7 MEMORY MAP APPENDIX B
B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
Ajustes Comunicaciones Remotas - Remote Communications Settings
Remote Comms
0x3A76 GSSE Comms F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3A77 W650 ID F009 1 R/W 33
0x3A98 Hold Time F005 1 R/W 2 [1000 , 60000] ms
0x3A9A Events Remote Out F012 1 R/W 1 0=DISABLED
1=ENABLED
Ajustes Entradas Remotas (32 elementos) - Remote Inputs Settings (32 items)
0x3A9B Remote Device 1 F009 1 R/W 33
0x3ABC Bit Pair 1 F012 1 R/W 1 0=NONE
1=DNA-1
2=DNA-2
--------
32=DNA-32
33=UserSt-1
34=UserSt-2
--------
96=UserSt-64
0x3ABD Default Value 1 F012 1 R/W 1 0=OFF
1=ON
2=Latest OFF
3=Latest ON
0x3ABE Remote Device 2 F009 1 R/W 33
0x3ADF Bit Pair 2 F012 1 R/W 1 0=NONE
1=DNA-1
2=DNA-2
--------
32=DNA-32
33=UserSt-1
34=UserSt-2
--------
96=UserSt-64
0x3AE0 Default Value 2 F012 1 R/W 1 0=OFF
1=ON
2=Latest OFF
3=Latest ON
... ... ... ... ... ... ... ...
... ... ... ... ... ... ... ...
... ... ... ... ... ... ... ...
0x3ED8 Remote Device 32 F009 1 R/W 33
0x3EF9 Bit Pair 32 F012 1 R/W 1 0=NONE
1=DNA-1
2=DNA-2
--------
32=DNA-32
33=UserSt-1
34=UserSt-2
--------
96=UserSt-64
0x3EFA Default Value 32 F012 1 R/W 1 0=OFF
1=ON
