GE Multilin W650 - Page 566

B-120 W650 Wind Generator Protection System GEK-113032A
B.7 MEMORY MAP APPENDIX B
B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
Datos Ecuaciones PLC - PLC Data
0x6000 PLC equations F009 R 12288
Datos Display Gráfico - LCD Data
0x9000 LCD configuration R 768
Bits de Maniobra (24 bits) - Commands
0xAFFE 0x0001 Operation 1 F001 W 1
0xAFFE 0x0002 Operation 2 F001 W 1
0xAFFE 0x0004 Operation 3 F001 W 1
0xAFFE 0x0008 Operation 4 F001 W 1
0xAFFE 0x0010 Operation 5 F001 W 1
0xAFFE 0x0020 Operation 6 F001 W 1
0xAFFE 0x0040 Operation 7 F001 W 1
0xAFFE 0x0080 Operation 8 F001 W 1
0xAFFE 0x0100 Operation 9 F001 W 1
0xAFFE 0x0200 Operation 10 F001 W 1
0xAFFE 0x0400 Operation 11 F001 W 1
0xAFFE 0x0800 Operation 12 F001 W 1
0xAFFE 0x1000 Operation 13 F001 W 1
0xAFFE 0x2000 Operation 14 F001 W 1
0xAFFE 0x4000 Operation 15 F001 W 1
0xAFFE 0x8000 Operation 16 F001 W 1
0xAFFF 0x0001 Operation 17 F001 W 1
0xAFFF 0x0002 Operation 18 F001 W 1
0xAFFF 0x0004 Operation 19 F001 W 1
0xAFFF 0x0008 Operation 20 F001 W 1
0xAFFF 0x0010 Operation 21 F001 W 1
0xAFFF 0x0020 Operation 22 F001 W 1
0xAFFF 0x0040 Operation 23 F001 W 1
0xAFFF 0x0080 Operation 24 F001 W 1
Identificación del Equipo - Relay Identification
0xB000 Relay model F009 R 8
0xB008 Firmware version F009 R 2
0xB018 Year(0=2000,1=2001,...) and part
of firmware compilation
F001 R 1
0xB019 Day and month of firmware
compilation
F001 R 1
0xB020 Address of PLC equations F005 R 2
0xB022 Address of LCD configuration F005 R 2
Eventos de Control y Panel de Alarmas - Control Events & Alarm Panel
0xF000 Status and acknowledge of the
192 control events
F001 R 24 Status = 24 first bytes
1st byte: 1st eight control events (First
event=bit less significant)
2nd byte: 2nd eight control events (Ninth
event=bit less significant)
. . .
Ack = 24 second bytes
25th byte: 1st eight control events (First
event=bit less significant)
26th byte: 2nd eight control events (Ninth
event=bit less significant)
. . .
