GEK-113032A W650 Wind Generator Protection System B-121
APPENDIX B B.7 MEMORY MAP
B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
Eventos de Control y Panel de Alarmas - Control Events & Alarm Panel (cont.)
0xF018 Indicate which control events are
configurated as alarm
F001 R 12 1st byte: 1st eight control events (First
event=bit less significant)
2nd byte: 2nd eight control events (Ninth
event=bit less significant)
. . .
0xF024 Date/Time of the 1-16 alarms F011 R 64
0xF064 Date/Time of the 17-32 alarms F011 R 64
0xF0A4 Date/Time of the 33-48 alarms F011 R 64
0xF0E4 Date/Time of the 49-64 alarms F011 R 64
0xF124 Date/Time of the 65-80 alarms F011 R 64
0xF164 Date/Time of the 81-96 alarms F011 R 64
0xF1A4 Date/Time of the 97-112 alarms F011 R 64
0xF1E4 Date/Time of the 113-128 alarms F011 R 64
0xF224 Date/Time of the 129-144 alarms F011 R 64
0xF264 Date/Time of the 145-160 alarms F011 R 64
0xF2A4 Date/Time of the 161-176 alarms F011 R 64
0xF2E4 Date/Time of the 177-192 alarms F011 R 64
0xF324 Alarm acknowledge F001 W 12 1st byte: 1st eight alarms (First alarm=bit
less significant)
2nd byte: 2nd eight alarms (Ninth
alarm=bit less significant)
. . .
Entradas Virtuales - Virtual Inputs
0xF430 64 Virtual Inputs (32 Latched +
32 Self Reset)
F001 R/W 4 2nd byte: 1st eight virtual inputs (First
virtual input=bit less significant)
1st byte: 2nd eight virtual inputs (Ninth
virtual input=bit less significant)
. . .
Nombre Fichero de Eventos - Events File Name
0xFE00 Name of the events file to read F009 W EVE.TXT: all snapshot-events are sent in
ASCII format
NEW_EVE.TXT: the new snapshot-
events are sent in ASCII format
EVE.BIN: all snapshot-events are sent in
BINARY format
NEW_EVE.BIN: the new snapshot-
events are sent in BINARY format
Forzado de Salidas por Comunicaciones - Forcing Outputs
0xFE20 Opening force output file F004 W 3 Write "OUTPUT"
0xFE28 Closing force output file F004 W 3 Write "OUTPUT"
0xFF20 Forcing outputs F004 W 5 First word = Board number;
Ficheros Oscilografía y Reporte de Faltas - Oscillography and Fault Report Files
0xFE40 Name of the oscillography/fault
report file to read
F009 W OSCXXX.DAT, OSCXXX.CFG,
OSCXXX.HDR,
FLTXXX.TXT (where XXX=001 to 999)
0xFF00 Character position of current
block within events file
F005 R 2
0xFF02 Size of currently-available data
block of events file
F004 R 1
0xFF03 Block of data requested events
file (122 items)
F004 R 1
0xFF40 Character position of current
block within osc file
F005 R 2
0xFF42 Size of currently-available data
block of osc file
F004 R 1
