GE P54C User Manual

DDB Signal
Name
DDB Signal
Number
Source Module Destination Module
External Trip A 535 1-pole / 3-pole trip, AR In Progress, CB Control
External Trip B 536 1-pole / 3-pole trip, AR In Progress, CB Control
External Trip C 537 1-pole / 3-pole trip, AR In Progress, CB Control
External Trip3ph 534 1-pole / 3-pole trip, AR In Progress, CB Control
F out of Range 319 Check Sync Signals
Force 3Pole Trip 533 CB Trip Conversion
IA< Start 864 AR Initiation
IB< Start 865 AR Initiation
IC< Start 866 AR Initiation
Inhibit AR 1420 AR In Progress, Force 3-phase Trip
Inhibit DB 1525 System Checks Voltage Monitor
Inhibit DL 1523 System Checks Voltage Monitor
Inhibit LB 1524 System Checks Voltage Monitor
Inhibit LL 1522 System Checks Voltage Monitor
Init 3P AR Test 1507 Trip Test
Init APh AR Test 1504 Trip Test
Init BPh AR Test 1505 Trip Test
Init Close CB 440 CB Control
Init CPh AR Test 1506 Trip Test
Init Trip CB 439 CB Control
Live Bus 886 System Checks Voltage Monitor (59)
3 Phase AR System Check
CB Manual Close S
ystem Check
Live Line 888 System Checks Voltage Monitor (59)
3 Phase AR System Check
CB Manual Close System Check
Lockout Alarm 860
AR In Progress
Pole Discrepancy
Man CB Unhealthy 304 CB Control (43)
MCB/VTS 438 System Checks Voltage Monitor
MCB/VTS CB CS 1521 System Checks Voltage Monitor
No C/S Man Close 305 CB Control (43)
OK Time 3P 1555 3-phase AR Dead Time (25)
Dead Time Start Enable
3-phase AR Dead Time
CB Autoclose
Prepare Reclaim Initiation
CB Healthy and System Check Timers
Pole Dead A 892 CB Trip Conversion
Pole Dead B 893 CB Trip Conversion
Pole Dead C 894 CB Trip Conversion
Pole Discrepancy 699 Pole Discrepancy (62) Pole Discrepancy
Reset Close Dly 443 CB Control
Reset Lockout 446 Reset CB Lockout
Seq Counter = 0 846 Sequence Counter (18) AR Modes Enable
P54A/B/C/E Chapter 7 - Autoreclose
P54xMED-TM-EN-1 145
