Object
Request
(Librar
y will parse)
Response
(Library will respond with)
Object
Number
Variation
Number
Description
Function Codes (dec) Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes (hex)
34 0 Analog Input Deadband (Variation
0 is used to r
equest default
variation)
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
34 1 16 Bit Analog Input Deadband 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
34 2
(default - see
note 1)
32 Bit Analog Input Deadband 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
34 3 Short Floating Point Analog Input
Deadband
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
40 0 Analog Output Status (Variation 0
is used to request default
variation)
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
40 1
(default - see
note 1)
32-Bit Analog Output Status 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
40 2 16-Bit Analog Output Status 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
40 3 Short Floating Point Analog
Output Status
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
41 1 32-Bit Analog Output Block 3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 28
27
(index)
(index)
129 response echo of request
41 2 16-Bit Analog Output Block 3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 28
27
(index)
(index)
129 response echo of request
41 3 Short Floating Point Analog
Output Block
3
4
5
6
(select)
(operate)
(dir
ect op)
(dir. op, noack)
17, 27, 28 (index) 129 response echo of request
50
1
(default - see
note 1)
Time and Date
1 (read) 07 (limited qty = 1) 129 response 07 (limited qty = 1)
2 (write) 07 (limited qty = 1)
60 0 Not defined
60 1 Class 0 Data 1 (read) 06 (no range, or all)
60 2 Class 1 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
60 3 Class 2 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
60 4 Class 3 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
P54A/B/C/E Chapter 17 - Communications
P54xMED-TM-EN-1 395
