Appendix B - Settings and Signals
P54A/B/C/E
B12
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Measured parameter
IA Differential 01 70
IA Differential
[Courier Number (current)]
Measured parameter
IB Differential 01 71
IB Differential
[Courier Number (current)]
Measured parameter
IC Differential 01 72
IC Differential
[Courier Number (current)]
Measured parameter
IA Bias 01 73
IA Bias
[Courier Number (current)]
Measured parameter
IB Bias 01 74
IB Bias
[Courier Number (current)]
Measured parameter
IC Bias 01 75
IC Bias
[Courier Number (current)]
Measured parameter
Ch1 L-R1 PropDly 01 76
Ch1 L-R1 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch2 L-R1 PropDly 01 77
Ch2 L-R1 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch1 L-R2 PropDly 01 90
Ch1 L-R2 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch2 L-R2 PropDly 01 91
Ch2 L-R2 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch1 L-R3 PropDly 01 92
Ch1 L-R3 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch2 L-R3 PropDly 01 93
Ch2 L-R3 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch1 L-R4 PropDly 01 94
Ch1 L-R4 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch2 L-R4 PropDly 01 95
Ch2 L-R4 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch1 L-R5 PropDly 01 96
Ch1 L-R5 PropDly
[Courier Number (time-seconds)]
Measured parameter
Ch2 L-R5 PropDly 01 97
Ch2 L-R5 PropDly
[Courier Number (time-seconds)]
Measured parameter
V1 Rem Magnitude 01 98
V1 Rem Magnitude
[Courier Number (voltage)]
Measured parameter
V1 Rem Phase Ang 01 99
V1 Rem Phase Ang
[Courier Number (angle)]
Measured parameter
Fault IA Local 01 A0
Fault IA Local
[Courier Number (current)]
Measured parameter
Fault IB Local
01
A1
Fault IB Local
