P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B15
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
IC Magnitude
IC Phase Angle 02 06
IC Phase Angle
[Courier Number (angle)]
IC Phase Angle
IN Derived Mag 02 09
IN Derived Mag
[Courier Number (current)]
IN Derived Mag
IN Derived Angle 02 0A
IN Derived Angle
[Courier Number (angle)]
IN Derived Angle
ISEF Magnitude 02 0B
ISEF Magnitude
[Courier Number (current)]
ISEF Magnitude
ISEF Angle 02 0C
ISEF Angle
[Courier Number (angle)]
ISEF Angle
I1 Magnitude 02 0D
I1 Magnitude
[Courier Number (current)]
I1 Magnitude
I2 Magnitude 02 0E
I2 Magnitude
[Courier Number (current)]
I2 Magnitude
I0 Magnitude 02 0F
I0 Magnitude
[Courier Number (current)]
I0 Magnitude
IA RMS 02 10
IA RMS
[Courier Number (current)]
IA RMS
IB RMS 02 11
IB RMS
[Courier Number (current)]
IB RMS
IC RMS 02 12
IC RMS
[Courier Number (current)]
IC RMS
VAB Magnitude 02 14
VAB Magnitude
[Courier Number (voltage)]
VAB Magnitude
VAB Phase Angle 02 15
VAB Phase Angle
[Courier Number (angle)]
VAB Phase Angle
VBC Magnitude 02 16
VBC Magnitude
[Courier Number (voltage)]
VBC Magnitude
VBC Phase Angle 02 17
VBC Phase Angle
[Courier Number (angle)]
VBC Phase Angle
VCA Magnitude 02 18
VCA Magnitude
[Courier Number (voltage)]
VCA Magnitude
VCA Phase Angle 02 19
VCA Phase Angle
[Courier Number (angle)]
VCA Phase Angle
VAN Magnitude 02 1A
VAN Magnitude
[Courier Number (voltage)]
VAN Magnitude
VAN Phase Angle 02 1B
VAN Phase Angle
[Courier Number (angle)]
VAN Phase Angle
VBN Magnitude
02
1C
VBN Magnitude
