P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B17
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
I1 Phase Angle 02 41
I1 Phase Angle
[Courier Number (angle)]
I1 Phase Angle
I2 Magnitude 02 42
I2 Magnitude
[Courier Number (current)]
I2 Magnitude
I2 Phase Angle 02 43
I2 Phase Angle
[Courier Number (angle)]
I2 Phase Angle
I0 Magnitude 02 44
I0 Magnitude
[Courier Number (current)]
I0 Magnitude
I0 Phase Angle 02 45
I0 Phase Angle
[Courier Number (angle)]
I0 Phase Angle
V1 Magnitude 02 46
V1 Magnitude
[Courier Number (voltage)]
V1 Magnitude
V1 Phase Angle 02 47
V1 Phase Angle
[Courier Number (angle)]
V1 Phase Angle
V2 Magnitude 02 48
V2 Magnitude
[Courier Number (voltage)]
V2 Magnitude
V2 Phase Angle 02 49
V2 Phase Angle
[Courier Number (angle)]
V2 Phase Angle
V0 Magnitude 02 4A
V0 Magnitude
[Courier Number (voltage)]
V0 Magnitude
V0 Phase Angle 02 4B
V0 Phase Angle
[Courier Number (angle)]
V0 Phase Angle
V1 Rem Magnitude 02 50
V1 Rem Magnitude
[Courier Number (voltage)]
V1 Rem Magnitude
V1 Rem Phase Ang 02 51
V1 Rem Phase Ang
[Courier Number (angle)]
V1 Rem Phase Ang
MEASUREMENTS 2
03
00
This column contains measurement parameters
A Phase Watts 03 01
A Phase Watts
[Courier Number (power)]
A Phase Watts
B Phase Watts 03 02
B Phase Watts
[Courier Number (power)]
B Phase Watts
C Phase Watts 03 03
C Phase Watts
[Courier Number (power)]
C Phase Watts
A Phase VArs 03 04
A Phase VArs
[Courier Number (VAr)]
A Phase VArs
B Phase VArs 03 05
B Phase VArs
[Courier Number (VAr)]
B Phase VArs
C Phase VArs 03 06
C Phase VArs
[Courier Number (VAr)]
C Phase VArs
