P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B19
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
3 Phase Watts - Rolling Demand
3Ph VArs RollDem 03 1C
3Ph VArs RollDem
[Courier Number (VAr)]
3 Phase VArs - Rolling Demand
IA Roll Demand 03 1D
IA Roll Demand
[Courier Number (current)]
IA Roll Demand
IB Roll Demand 03 1E
IB Roll Demand
[Courier Number (current)]
IB Roll Demand
IC Roll Demand 03 1F
IC Roll Demand
[Courier Number (current)]
IC Roll Demand
3Ph W Peak Dem 03 20
3Ph W Peak Dem
[Courier Number (power)]
3 Phase Watts - Peak Demand
3Ph VAr Peak Dem 03 21
3Ph VAr Peak Dem
[Courier Number (VAr)]
3 Phase VArs - Peak Demand
IA Peak Demand 03 22
IA Peak Demand
[Courier Number (current)]
IA Peak Demand
IB Peak Demand 03 23
IB Peak Demand
[Courier Number (current)]
IB Peak Demand
IC Peak Demand 03 24
IC Peak Demand
[Courier Number (current)]
IC Peak Demand
Reset Demand 03 25 No
No
Yes
[Indexed String]
Reset Demand
Thermal State 03 26
Thermal State
[Courier Number (percentage)]
Thermal State
Reset Thermal 03 27 No
No
Yes
[Indexed String]
Reset Thermal
df/dt 03 29
Bit 31 = sign
Bits 30-23 = e7 - e0
Implicit 1.
Bits 22-0 = f22 - f0
[Courier Number (Hz/sec)]
df/dt
MEASUREMENTS 3
04
00
This column contains measurement parameters
IA Local 04 01
IA Local
[Courier Number (current)]
IA Local
IB Local 04 03
IB Local
[Courier Number (current)]
IB Local
IC Local 04 05
IC Local
[Courier Number (current)]
IC Local
IA remote 1 04 09
IA remote 1
[Courier Number (current)]
IA remote 1
